| Catalogue No. |
PFP/IB/220 |
| Type of Ex-Protection |
AS PER IS 2148-2004 / IEC-60079-1:2007 |
| Zone Classification |
Zone 1 & Zone 2 |
| Gas Group |
Gas Group I, IIA, IIB |
| Ingress IP Protection |
IP-65 IS / IEC60529-2001 |
| Material of Contraction |
Die Cast Aluminum Alloy LM6 |
| Green Push Button |
4 Nos. PUSH with NO Contact element for 10 AMP |
| Switch |
1 NO 12A DP, ON-OFF Switch 250V A.C. 50Hz |
| Glass Window |
100 X 50 mm with Type "A" Toughened with Mt. Clamp 02 Nos. |
| Terminal |
As Per Client Requirements |
| Paint |
Epoxy Polyester Powder Coating |
| Earthling |
Internal: 01 No. & External: 2 Nos. |
| Cable Entry |
As Per Client Requirements |
| Hardware |
Stainless Steel |
