Technical Specification
| Catalogue No. | PFP/LGI |
| Type of Ex-Protection | Ex-d, AS PER IS 2148-2004/IEC-60079-1:2007 |
| Zone Classification | Zone 1 & Zone 2 |
| Gas Group | Gas Group I, IIA, IIB |
| Ingress IP Protection | IP-65 IS / IEC60529-2001 |
| Material of Contraction | Die Cast Aluminum Alloy LM6 |
| Rating | 15W, 250V, AC - T6 25W, 250V, AC - T6 |
| Wire Guard | M.S. White Powder Coated |
| Lamp Holder | Enclosed Break Porcelin E-27 |
| Glass | TYPE "A" Toughened AS PER IS:2206 / 84 (PART-I) |
| Paint | Epoxy Polyester Powder Coating |
| Earthling | Internal: 01 No. & External: 2 Nos. |
| Cable Entry | 02 Nos. for M20 (3/4” ET) |
| Hardware | Stainless Steel |
