Technical Specification
| Catalogue No. | PFP/IB/08 |
| Type of Ex-Protection | AS PER IS / IEC-60079-1:2007 |
| Zone Classification | Zone 1 & Zone 2 |
| Gas Group | Gas Group I, IIA, IIB |
| Ingress IP Protection | IP-65 IS / IEC60529-2001 |
| Material of Contraction | Die Cast Aluminum Alloy LM6 |
| Glass Window | 1 No. 96 X 96 mm Glass Window |
| Terminal | 12 Way Clip on Rail or Strip Type |
| Paint | Epoxy Polyester Powder Coating |
| Earthling | Internal: 01 No. & External: 2 Nos. |
| Cable Entry | 03-05 Nos. for M20 (3/4” ET) |
| Hardware | Stainless Steel |
